Area of application Industry Machine control

Nuvo-7006E

Lüfterloser Embedded-PC mit Intel Core i7 / i5 / i3 CPU der 9./8. Generation

Fanless

Robust

Longterm

Product information "Nuvo-7006E"

The Nuvo-7006E is a highly advanced Rugged Embedded Computer, specifically designed for industrial automation, surveillance, and AI-based systems. Featuring cutting-edge technology and a robust design, this system sets new standards in performance and connectivity.

Main Features of the Nuvo-7006E Rugged Embedded Computer

Intel® Core™ Processors for Peak Performance: Powered by Intel® Core™ processors of the 8th and 9th generations, the Nuvo-7006E delivers exceptional computing power and reliability for demanding applications.
Durable Industrial Design: This model is built for use in challenging environments, offering protection against extreme temperatures, vibrations, and shocks to ensure consistent performance.
Enhanced Graphics Performance: Integrated Intel® UHD Graphics provide sharp visualizations and support multiple displays, ideal for complex applications.
Flexible Expansion Options: Featuring multiple PCIe slots, the Nuvo-7006E offers the ability to customize and expand the system to meet individual requirements.
Seamless System Integration: This embedded PC is compatible with various operating systems and integrates effortlessly into existing infrastructures.

Why the Nuvo-7006E is the Ideal Rugged Embedded Computer

The Nuvo-7006E combines cutting-edge technology, durable construction, and flexible expansion capabilities to meet the most demanding industrial applications. Whether for automation, surveillance, or AI systems, this embedded PC delivers reliable performance and future-proof solutions.

Choose the Nuvo-7006E Rugged Embedded Computer and optimize your industrial processes with a powerful, robust, and versatile platform.

Technical details

Add-ons:	Full-size Mini PCIe, Full-size mSATA port, M.2 2242 B key, M.2 2280 M key, PCIe x16 Gen3 Slot, SIM Socket
Audio:	1x 3,5mm jack mic in & speaker out
CPU:	Intel® Core™ i9, Intel® Core™ i7, Intel® Core™ i5, Intel® Core™ i3, Intel® Celeron®, Intel® Pentium®
CPU Generation:	8th generation, 9th generation
CPU Socket:	LGA1151
Chipset:	Intel® Q370
DC Input:	3-pin pluggable terminal block
Ethernet:	Gigabit
Ethernet Ports:	1x, 2x, 3x, 4x, 5x, 6x
Intel AMT:	AMT 12.0
Internal Graphics:	Intel® UHD Graphics 630
Memory:	1x DDR4 Slot, 2x DDR4 Slots
Memory capacity:	2 GB, 4 GB, 8 GB, 16 GB, 32 GB, 64 GB
Mounting:	DIN-rail mount (optional), Wall-mount
Operating system:	Windows 10, Windows 10 IoT, Windows 11
Power supply:	8 ~ 35V DC
RAID:	RAID 0, RAID 1
Remote:	3-pin pluggable terminal block for remote control, PWR LED Output
Serial Ports:	RS-232, RS-422, RS-485
Storage:	2,5" SSD, 2x 2,5" SSD/HDD, M.2 2280 NVME
TPM:	TPM 2.0
USB:	USB 3.1 Gen 1, USB 3.1 Gen 2
USB Ports:	1x, 2x, 3x, 4x, 5x, 6x, 7x, 8x
Video:	DVI-D, DisplayPort, VGA
