AC-IMX390-H60
GMSL2 camera with Sony IMX390 sensor and a 2MP resolution (1920x1080)
Features
- SONY IMX390 CMOS Sensor and GEO SEMI GW5200 ISP
- 1920x1080 uncompressed UYVY video output
- IP67 + IP69K waterproof on the lens side
- Enhanced edge focus and lens centering via 5-axis active adjustmen
- Object Distance 3.2M to infinity
Product information "AC-IMX390-H60"
The AC-IMX390 series cameras feature advantages such as IP67 waterproof, high dynamic range (120dB HDR), auto white balance (AWB), and LED flicker mitigation (LFM), making them ideal choices for computer vision applications on mobile platforms in outdoor environments where illumination conditions are constantly changing.
Technical details
| CMOS : | SONY IMX390, 1/2.7” optical format with 3μm x 3μm pixel size |
|---|---|
| Connector: | Male FAKRA Z Connector |
| Current Consumption : | ≤ 165mA @ 12V |
| FPS: | 30 FPS (Fixed) |
| HDR (High Dynamic Range): | 120dB |
| ISP: | GEO SEMI GW5200 |
| LFM (LED Flicker Mitigation): | Yes |
| Lens Mounting: | 5-axis active adjustment with adhesive dispense |
| Operating Temperature: | -40°C ~ 85°C |
| Screen resolution: | 2MP (1920 x 1080) |
| Serializer: | MAX9295 |
| Video Format: | YUV422 (UYVY) |
| Waterproof: | IP67 + IP69K on the lens side IP67 on the FAKRA side, waterproof FAKRA connector |
