Nuvo-8108GC-QD
Industrial-grade edge AI platform with support for NVIDIA® RTX A6000/A4500 GPU.
Features
- Supports an NVIDIA® RTX A6000 / A4500 graphics card
- Intel® Xeon® E or 9th/8th Gen Core™ i7/i5 CPU
- Up to 128 GB DDR4-2133 RAM (4 SODIMM slots)
- 2 x16 and 2 x8 PCIe slots (Gen3) for expansion cards
- 8–35V wide-range input with integrated ignition control
- Suitable for harsh environments with temperatures ranging from -25°C to 60°C
The Nuvo-8108GC-QD, the latest system in the popular Nuvo-8108GC series, is a rugged edge AI platform specifically designed for NVIDIA® RTX A6000 and RTX A4500 Ampere GPUs. These durable GPUs provide massive computing power, opening up new horizons in terms of reliability and availability for GPU-accelerated edge AI applications, such as autonomous driving, visual inspection, and intelligent video analysis.
With its Intel® Xeon® E or 8th/9th Gen Core™ CPU (up to 8 processor cores/16 threads) and the workstation-proven Intel® C246 chipset, which supports up to 128 GB DDR4 memory (ECC or non-ECC), the system serves as a solid foundation for a powerful edge AI computing platform. The system features a sophisticated thermal design for heat dissipation, ensuring optimal GPU performance even in hot environments. Additionally, the Nuvo-8108GC-QD has a dedicated mounting bracket for the RTX A6000/A4500, securely holding the GPU in the PCIe slot. Together with the patented vibration-damping brackets*, the particularly robust construction enables operation in environments exposed to intense vibrations and shocks.
With the inclusion of the RTX A6000/A4500 in Neousys' GPU computer portfolio, an edge AI platform with a durable system and up to 38.7 TFLOPS of computing power is now available. With its proven industrial-grade design for high performance and guaranteed thermal efficiency, along with a particularly robust mechanical design, the Nuvo-8108GC-QD stands out for its unprecedented system longevity, computing power, flexibility, and reliability for edge AI computing.
Technical details
| Add-ons: | 2x PCIe x16 Gen3 Slot, Full-size Mini PCIe, Full-size mSATA port, M.2 2242 B key, M.2 2280 M key, PCIe x16 Gen3 Slot, SIM Socket |
|---|---|
| Audio: | 1x 3,5mm jack mic in & speaker out |
| CPU: | Intel® Xeon E, Intel® Core™ i7, Intel® Core™ i5, Intel® Core™ i3 |
| CPU Generation: | 8th generation, 9th generation |
| CPU Socket: | LGA1151 |
| Certificates: | CE/ FCC Class A, according to EN 55032 & EN 55024, MIL-STD-810G, Method 514.6, Category 4, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II |
| Chipset: | Intel® C246 |
| DC Input: | 2x 4-pin pluggable terminal block |
| Ethernet: | Gigabit |
| Ethernet Ports: | 1x, 2x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Ignition control: | Yes |
| Intel AMT: | AMT 12.0 |
| Internal Graphics: | Intel® UHD Graphics 630 |
| Memory: | 1x DDR4 Slot, 2x DDR4 Slots, 3x DDR4 Slots, 4x DDR4 Slots |
| Memory capacity: | 4 GB, 8 GB, 16 GB, 32 GB, 64 GB, 128 GB |
| Mounting: | Damping brackets |
| Operating Temperature: | -25°C ~ 50°C |
| Operating system: | Linux, Windows 10, Windows 10 IoT |
| Power supply: | 8 ~ 48V DC |
| RAID: | RAID 0, RAID 1 |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | 2,5" SSD, 2x 2,5" SSD/HDD, M.2 2280 NVME |
| TPM: | TPM 2.0 |
| USB: | USB 2.0, USB 3.2 Gen 1, USB 3.2 Gen 2 |
| USB Ports: | 1x, 2x, 3x, 4x, 5x |
| Video: | DVI-D, DisplayPort, VGA |
