Nuvo-5501-DIO
Intel® 6th-Gen Core™ i7/i5/i3 compact fanless rugged embedded computer with 3x GbE and up to 16 GB RAM
Features
- Intel® 6th Gen Core™ i7/i5/i3 LGA1151 CPU
- Up to 16 GB RAM
- 3 Gigabit Ethernet ports, 4x USB 3.0
- 4x serial RS232/422/485 interfaces
- VGA and DVI monitor outputs
- 1x 2.5‘ / 3.5’ HDD/SSD
- -25°C ~ 70°C Operating temperature
- 8-CH isolated DI and 8-CH isolated DO
Product information "Nuvo-5501-DIO"
The Nuvo-5501-DIO is a cost-effective, fanless, and compact embedded PC equipped with Intel® Skylake CPUs. This device delivers modern performance and reliable operation, even in demanding environments. With the LGA1151 socket, users have access to a wide range of configuration options, from 35W 6th Generation Intel® Core™ i processors to Celeron® models, meeting various requirements.
Main Features of the Compact Industrial PC Nuvo-5501-DIO
- Compact Design: The Nuvo-5501-DIO is the most compact fanless embedded controller supporting Skylake LGA1151 socket CPUs. Measuring just 221 x 173 x 76 mm, it is ideal for use in confined spaces.
- Diverse I/O Interfaces: The Nuvo-5501-DIO features front-accessible interfaces, including 3 GbE, 4 USB 3.0, 4 COM ports, and an 8-CH DI/8-CH DO port, providing maximum flexibility for industrial applications.
- Enhanced Storage Options: The chassis accommodates a 3.5-inch hard drive and supports the latest storage technologies to meet the needs of modern applications.
- Reliability and Performance: The Nuvo-5501-DIO is specifically designed for industrial environments, offering an uncompromising combination of reliability and performance.
- Cost-Effective Solution: With its attractive price-performance ratio, the Nuvo-5501-DIO is the ideal choice for a wide range of industrial applications.
Why the Nuvo-5501-DIO is the Ideal Compact Industrial PC
The Nuvo-5501-DIO combines a space-saving design, versatile connectivity, and reliable performance in a compact form factor. It is the perfect solution for industrial applications where space, functionality, and reliability are essential.
Choose the Compact Industrial PC Nuvo-5501-DIO to implement your industrial applications efficiently and reliably.
Technical details
| Add-ons: | Full-size Mini PCIe, M.2 2242 B key, SIM Socket |
|---|---|
| CPU: | Intel® Core™ i7, Intel® Core™ i5, Intel® Core™ i3, Intel® Celeron®, Intel® Pentium® |
| CPU Generation: | 6th generation |
| CPU Socket: | LGA1151 |
| Certificates: | CE/FCC Class A, according to EN 55022 & EN 55024, CE/ FCC Class A, according to EN 55032 & EN 55024, IEC60068-2-27, IEC60068-2-64 |
| Chipset: | Intel® H110 |
| DC Input: | 3-pin pluggable terminal block |
| DIO: | 8-CH isolated DI und 8-CH isolated DO |
| Ethernet: | Gigabit |
| Ethernet Ports: | 1x, 2x, 3x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Internal Graphics: | Intel® HD graphics 530 |
| Memory: | 1x DDR4 Slot |
| Memory capacity: | 2 GB, 4 GB, 8 GB, 16 GB |
| Mounting: | DIN-rail mount (optional), Wall-mount |
| Operating Temperature: | -25°C ~ 70°C |
| Operating system: | Linux, Windows 7, Windows 10, Windows 10 IoT |
| Power supply: | 8 ~ 35V DC |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | 2,5" SSD, mSATA SSD |
| USB: | USB 2.0, USB 3.0 |
| USB Ports: | 1x, 2x, 3x, 4x, 5x, 6x |
| Video: | DVI-D, VGA |
