Area of application Industry Machine control

Nuvo-5002P

Lüfterloser Embedded-PC mit Intel® 6. Gen Skylake Core™ i7 / i5 / i3 CPU

50 W
Longterm
High-End

Features

  • Intel® 6th Gen Core™ i3/i5/i7/Pentium/Celeron CPU
  • Up to 32GB DDR4-2133 SD-RAM (two SO-DIMM slots)
  • USB 3.0, VGA, DVI, and DisplayPort connections
  • 2x 2.5" SSD (+RAID 0/1) and 1x full-size mSATA slot
  • Fanless operation with a wide temperature range of -25°C to 70°C
  • PCI cassette and MezIO interface for functionality extension
  • 2x Gigabit Ethernet ports
Add-ons
Ethernet Ports
PoE
Product information "Nuvo-5002P"

Immerse yourself in the world of the Neousys Nuvo-5002P, a powerful embedded industrial PC specifically designed for applications in industrial automation, surveillance, and AI-based systems. This innovative system sets new standards in terms of connectivity and performance.

  • Intel® Core™ Processors 6th Generation: The Nuvo-5002P is powered by powerful Intel® Core™ processors from the 6th generation, providing outstanding computing power and reliability.
  • Advanced PCI Interface: The Nuvo-5002P offers an advanced PCI interface to connect additional expansion cards and extend functionality according to individual requirements.
  • Robust Industrial Design: The Nuvo-5002P is designed for use in demanding industrial environments, meeting the highest standards for temperature resistance, vibration, and shock resistance to ensure reliable performance.
  • Future-Ready Graphics Performance: The integrated Intel® HD Graphics ensures impressive image quality and effortlessly supports multiple displays, optimizing visualization in demanding applications.
  • Cross-Compatible: This embedded PC is compatible with a variety of operating systems, allowing seamless integration into existing systems.

The Neousys Nuvo-5002P sets new standards for powerful embedded PCs and defines the future of industrial automation. Experience advanced technology and a robust design at the highest level. Harness the unique performance and versatility of the Nuvo-5002P for your individual industrial applications.

Technical details

Add-ons: Full-size Mini PCIe, Full-size mSATA port, MezIO® Port, SIM Socket
Audio: Microphone input, Speaker out
CPU: Intel® Core™ i7, Intel® Core™ i5, Intel® Core™ i3, Intel® Celeron®, Intel® Pentium®
CPU Generation: 6th generation
CPU Socket: LGA1151
Chipset: Intel® Q170
DC Input: 3-pin pluggable terminal block
Ethernet: Gigabit
Ethernet Ports: 1x, 2x
Humidity: 10% ~ 90% (non-condensing)
Intel AMT: AMT 11
Internal Graphics: Intel® HD graphics 530
Memory: 1x DDR4 Slot, 2x DDR4 Slots
Memory capacity: 2 GB, 4 GB, 8 GB, 16 GB, 32 GB
Mounting: DIN-rail mount (optional), Wall-mount
Operating Temperature: -25°C ~ 70°C
Operating system: Linux, Windows 7, Windows 8, Windows 10, Windows 10 IoT
Power supply: 8 ~ 35V DC
RAID: RAID 0, RAID 1
Remote: 10-Pin Wafer Connector (Remote On/Off Control & Status LED Output)
Serial Ports: RS-232, RS-422, RS-485
Storage: 2,5" SSD, 2x 2,5" SSD/HDD
TPM: TPM 2.0
USB: USB 2.0, USB 3.0
USB Ports: 1x, 2x, 3x, 4x, 5x, 6x, 7x, 8x
Video: DVI-D, DisplayPort, VGA
Downloads

Suitable MezIO® modules

MezIO-C180-50
4x RS-232/422/485 and 4x RS-232 Ports via 68-Pin SCSI-II Connector
MezIO-D230-50
16-Channel Isolated DI and 16-Channel Isolated DO MezIO® Module
MezIO-G4P
4-Port GbE MezIO Expansion Card with 9.5 kB Jumbo Frame Support
MezIO-V20
MezIO® Module with 16 Operating Modes for Ignition Control Function in Vehicles
MezIO-U4-50
4-Port USB 3.1 Typ A MezIO® Modul with 5Gbps
