Nuvo-5006E-PoE
Lüfterloser Embedded-PC mit Intel® 6. Gen Skylake Core™ i7 / i5 / i3 CPU
Features
- Intel® 6th Gen Core™ i3/i5/i7/Pentium/Celeron CPU
- Up to 32GB DDR4-2133 SD-RAM (two SO-DIMM slots)
- USB 3.0, VGA, DVI, and DisplayPort connections
- 2x 2.5" SSD (+RAID 0/1) and 1x full-size mSATA slot
- Fanless operation with a wide temperature range of -25°C to 70°C
- PCIe cassette and MezIO interface for functionality extension
- 6x Gigabit Ethernet ports, 4 of which have PoE+ functionality
Product information "Nuvo-5006E-PoE"
Experience the groundbreaking performance of the Neousys Nuvo-5006E-PoE, an embedded industrial PC specifically designed for applications in industrial automation, surveillance, and AI-based systems. This innovative system sets standards in terms of connectivity and performance, integrating advanced Power-over-Ethernet (PoE) technology.
- Intel® Core™ Processors 6th Generation: The Nuvo-5006E-PoE is powered by powerful Intel® Core™ processors from the 6th generation, providing outstanding computing power and reliability.
- PoE+ Innovation: The system features Power-over-Ethernet (PoE) interfaces that allow simultaneous transmission of data and power over a single Ethernet cable. This significantly simplifies the installation and maintenance of PoE-enabled devices such as cameras and sensors.
- Robust Industrial Design: The Nuvo-5006E-PoE is designed for use in demanding industrial environments, meeting the highest standards for temperature resistance, vibration, and shock resistance to ensure reliable performance.
- Future-Ready Graphics Performance: The integrated Intel® HD Graphics ensures impressive image quality and effortlessly supports multiple displays, optimizing visualization in demanding applications.
- Versatile Expansion Options: With a wide range of PCIe and PCI slots, the Nuvo-5006E-PoE offers flexible expansion options to meet individual requirements.
- Cross-Compatible: This embedded PC is compatible with a variety of operating systems, allowing seamless integration into existing systems.
The Neousys Nuvo-5006E-PoE redefines the standards for powerful embedded PCs in a new way. Experience the future of industrial automation with this groundbreaking system that combines advanced technology, PoE connectivity, and a robust design at the highest level. Harness the unique performance and versatility of the Nuvo-5006E-PoE for your individual industrial applications.
Technical details
| Add-ons: | Full-size Mini PCIe, Full-size mSATA port, MezIO® Port, SIM Socket |
|---|---|
| Audio: | Microphone input, Speaker out |
| CPU: | Intel® Core™ i7, Intel® Core™ i5, Intel® Core™ i3, Intel® Celeron®, Intel® Pentium® |
| CPU Generation: | 6th generation |
| CPU Socket: | LGA1151 |
| Chipset: | Intel® Q170 |
| DC Input: | 3-pin pluggable terminal block |
| Ethernet: | Gigabit |
| Ethernet Ports: | 1x, 2x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Intel AMT: | AMT 11 |
| Internal Graphics: | Intel® HD graphics 530 |
| Memory: | 1x DDR4 Slot, 2x DDR4 Slots |
| Memory capacity: | 2 GB, 4 GB, 8 GB, 16 GB, 32 GB |
| Mounting: | DIN-rail mount (optional), Wall-mount |
| Operating Temperature: | -25°C ~ 70°C |
| Operating system: | Linux, Windows 7, Windows 8, Windows 10, Windows 10 IoT |
| Power supply: | 8 ~ 35V DC |
| RAID: | RAID 0, RAID 1 |
| Remote: | 10-Pin Wafer Connector (Remote On/Off Control & Status LED Output) |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | 2,5" SSD, 2x 2,5" SSD/HDD |
| TPM: | TPM 2.0 |
| USB: | USB 2.0, USB 3.0 |
| USB Ports: | 1x, 2x, 3x, 4x, 5x, 6x, 7x, 8x |
| Video: | DVI-D, DisplayPort, VGA |
