NRU-240S-AWP-JAO32
IP66 Waterproof AGX Orin Computer with 8x GMSL2, 4x PoE+ GbE, and 1x 10GbE Ports
Features
- Powered by NVIDIA® Jetson AGX Orin™ SoM
- IP66 water and dust resistant
- Supports 8x GMSL2 automotive cameras via FAKRA Z connectors
- 4x PoE+ GbE and 1x 10GBASE-T via M12 X-coded connectors
- 2x isolated CAN 2.0, 1x RS232, and 1x isolated RS485 via M12 A-coded connectors
- 4x PoE+ GbE and 1x 10GBASE-T via M12 X-coded connectors
- 1x system monitoring port through automotive-grade MCU
- 8V to 48V wide-range DC input with integrated ignition power control
The Neousys NRU-230V-AWP is a rugged, IP66 waterproof NVIDIA® Jetson AGX Orin computer specifically designed for edge AI applications in harsh environments. Its areas of application range from traffic monitoring to food and chemical factories, mining, construction, agriculture, and ports.
With its optimized mechanical design, standardized cable set, and carefully selected waterproof connectors, the NRU-230V-AWP aims to redefine rugged edge AI with waterproof features at an affordable price.
Powerful AI Inference
Powered by NVIDIA® Jetson AGX Orin, the NRU-230V-AWP offers up to 275 Sparse TOPS (INT8) AI inference performance and can transcode up to 22 1080P video streams simultaneously.
Versatile Camera Support
The NRU-230V-AWP meets versatile camera requirements for vision-based AI applications through:
- 4x waterproof M12 PoE+ GbE ports for industrial GigE cameras or IP cameras.
- 8x waterproof GMSL2 FAKRA ports for automotive cameras or industrial stereo cameras.
- A waterproof Type-C port with 4K DisplayPort output for real-time surround-view ADAS applications.
- A waterproof 10GbE port for high-speed data communication.
Vehicle Compatibility
For vehicle use, the NRU-230V-AWP is equipped with:
- A wide 8V to 48V DC input range and ignition power control.
- 2x isolated CAN bus ports.
- 1x RS232 port and 1x isolated RS485 port.
- Two Mini-PCIe slots for CAN/COM/WiFi modules.
- An M.2 B-Key slot for 4G LTE/5G NR cellular modules.
Storage Options
The NRU-230V-AWP features:
- 64 GB eMMC on the Orin module.
- An M.2 2280 NVMe slot for fast SSD read/write speeds.
- Two internal 2.5-inch SSD bays for storage expansion.
System Monitoring
A system monitoring port reports the current power, thermal, and Jetson status via an integrated automotive-grade MCU, enabling potential functional safety system design.
The integration of IP66 waterproofing, AGX Orin AI performance, and extensive built-in I/O provides a sweet spot between ruggedness, performance, and cost. This makes the NRU-230V-AWP an ideal waterproof edge AI platform for industrial vehicles, outdoor AMR, edge inspection, and roadside applications.
Technical details
| Add-ons: | Full-size Mini PCIe, M.2 3052 B key, SIM Socket |
|---|---|
| CPU: | NVIDIA® Jetson AGX Orin™ system-on-module (SOM), comprising NVIDIA® Ampere GPU and Arm Cortex-A78AE CPU |
| Certificates: | MIL-STD-810H, Method 514.8, Category 4, MIL-STD-810H, Method 516.8, Procedure I |
| DC Input: | M12 A-coded 5-pin port |
| Ethernet Ports: | 1x 10 Gigabit Ethernet port via M12 X-coded 8-pin connector, 4x Gigabit Ethernet ports by Intel® I350 via M12 X-coded 8-pin connector |
| IP protection class: | IP66 |
| Ignition control: | Yes |
| Memory: | 32GB/ 64GB LPDDR5 (JAO 32GB/ JAO 64GB) @ 3200 MHz on SOM |
| Mounting: | Wall-mount |
| Operating Temperature: | -25°C ~ 70°C |
| PoE: | IEEE 802.3at PoE+ PSE for Port 1 to Port 4, 100 W total power budget |
| Power supply: | 8 ~ 48V DC |
| Serial Ports: | RS-232, RS-485 |
| Storage: | 2x 2,5" SSD/HDD, M.2 2280 NVME |
| USB: | USB-C, USB 2.0, USB 3.2 Gen 1 |
| USB Ports: | 2x |
| eMMC: | 64GB eMMC 5.1 on SOM |
