NRU-156-JON8
NVIDIA® Jetson Orin™ NX Edge AI computer with 8GB RAM, six USB 3.2 ports and flattop heatsink
Features
- Powered by an NVIDIA® Jetson Orin™ NX-SoM in combination with JetPack 5.1.1
- 8 GB LPDDR5 RAM
- Up to 100 TOPS of computing power for AI inferencing
- 6x USB 3.2 ports for connecting cameras
- RS-232/485 port
- M.2 2242 M-Key NVME slot
- Operating temperature range from -25 °C to 60 °C, fanless
The NRU-156-JON8 is a fanless compact edge AI computer with Jetson Orin NX and independent USB 3 camera connectivity. The special flattop heatsink is specially designed for installation in sealed enclosures, for example for applications in metal processing or food manufacturing, in smart agriculture and in road-side applications where they are protected in environments where dust, metal particles or liquids are present.
Thanks to the energy-efficient NVIDIA® Jetson Orin™ NX, the NRU-156-FT series delivers up to 100 TOPS of inferencing performance in a 25 W energy pack. The NRU-156-JON8 offers six USB 3.2 ports for industrial USB 3 cameras, all of which have full bandwidth to support multiple video inputs for visual inspections at edge nodes.
The flattop heatsink design supports even more application scenarios, as the NRU-150-FT series can also be installed in sealed enclosures where the heat is dissipated to the outside surface, enabling fanless operation over a wide temperature range from -25 °C to 60 °C. This feature makes the NRU-156-JON8 ideal for environments such as dusty roadsides and farms with high humidity. This feature makes the NRU-156-JON8 ideal for environments such as dusty roadsides, farms with high humidity and harbours. These systems can also be used in various AI-based applications for production automation in the metal, wood, food and chemical industries.
Thanks to the integration of USB 3.2 ports for full-bandwidth camera connectivity, 100 TOPS of AI inferencing performance, the special flattop heatsink for mounting in enclosures and a wide variety of NVIDIA AI JetPack toolkits, the NRU-156-FT series opens up new possibilities for visual inspection at edge nodes in harsh environments where dust protection, waterproofing or fire resistance are required.
Technical details
| CPU: | NVIDIA® Jetson Orin™ NX |
|---|---|
| Certificates: | CE/FCC Class A, according to EN 55032 & EN 55035, MIL-STD-810H, Method 514.8, Category 4, MIL-STD-810H, Method 516.6 |
| DC Input: | 6-contact terminal block |
| Design: | Flat-Top Heatsink |
| Ethernet: | Gigabit |
| Ethernet Ports: | 1x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Memory capacity: | 8 GB |
| Mounting: | Wall-mount |
| Operating Temperature: | -25°C ~ 60°C |
| Operating system: | NVIDIA JetPack 5.1.1 (vorinstalliert) |
| PoE: | No |
| Power supply: | 12V DC |
| Serial Ports: | RS-232, RS-485 |
| Storage: | M.2 2242 M Key NVMe |
| USB: | USB 2.0, USB 3.2 Gen 1 |
| USB Ports: | 1x, 2x, 3x, 4x, 5x, 6x, 7x |
| Video: | DisplayPort |
