LPC-P150S-2CxM
Fanless 15" Capacitive Panel PC with 9th Gen Intel Core i3/i5/i7 CPU, up to 64GB RAM, and 768p Resolution.
Features
- Intel® 9th Gen Core™ i3/i5/i7 Processor
- Up to 64 GB DDR4 RAM
- 1x M.2 2280 NVMe
- 15" LCD Display with 768p Resolution
- 4x USB 3.1, 2x Gigabit LAN, 3x DisplayPort
- Fanless Rugged Design
- IP65-Protected Front
- VESA Mounting
- Wide Operating Temperature Range of -20 ~ 60°C
The Panel PC LPC-P150S-2Cx from Elgens offers an optimal combination of performance and reliability for industrial applications. Featuring a modern 15-inch LCD display with a resolution of 1024 x 768 pixels, it delivers sharp images and clear visuals that meet even the most demanding requirements.
At the heart of this Panel PC is a powerful 9th Gen Intel i3/i5/i7 35W processor, ensuring smooth and reliable performance even for demanding applications. Thanks to its IP65 front panel, the LPC-P150S-2Cx is protected against dust and water, making it ideal for environments where reliability is crucial.
With a brightness of 400 nits and LED backlighting, this device provides clear and easily readable images, even in brightly lit environments. Additionally, the fanless design with only 35W power consumption makes it not only energy-efficient but also nearly silent in operation.
For maximum flexibility in data storage, the LPC-P150S-2Cx features two externally accessible storage bays for 2.5" SSDs as well as an M.2 2280 NVMe slot, allowing users to easily manage and store their data. With VESA 75 x 75 / 100 x 100 standard mounting points, the Panel PC can be conveniently installed in various locations.
Thanks to its wide operating temperature range of -20 to 60°C, the LPC-P150S-2Cx can be used even in extreme conditions.
With its rugged design, powerful hardware, and extensive feature set, the Elgens LPC-P150S-2Cx Panel PC is the ideal solution for industrial applications where performance, reliability, and flexibility are key.
Technical details
| Add-ons: | Full-size Mini PCIe, M.2 2242 B key, M.2 2280 M key, PCIe x16 Gen3 Slot |
|---|---|
| CPU: | Intel® Core™ i7, Intel® Core™ i5, Intel® Core™ i3 |
| CPU Generation: | 9th generation |
| Certificates: | FCC / CE Class A Certification, IEC60068-2-64 |
| DC Input: | 3-pin pluggable terminal block |
| Display size: | 15" |
| Ethernet: | Gigabit |
| Ethernet Ports: | 1x, 2x |
| Humidity: | 10% ~ 90% (non-condensing) |
| IP protection class: | IP65 |
| Memory: | 1x DDR4 Slot, 2x DDR4 Slots |
| Memory capacity: | 4 GB, 8 GB, 16 GB, 32 GB, 64 GB |
| Mounting: | VESA, Wall-mount |
| Operating Temperature: | -20°C ~ 60°C |
| Operating system: | Linux, Windows 10, Windows 10 IoT |
| Power supply: | 19~28V DC |
| Screen resolution: | 1024 x 768 |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | M.2 2242 NVMe, M.2 2280 NVME |
| Touch: | Projected Capacitive Touch |
| USB: | USB 3.1 Gen 1 |
| USB Ports: | 1x, 2x, 3x, 4x |
| Video: | DisplayPort |
