LPC-P101WAG-3T5
Fanless 10.1" Capacitive Panel PC with 800p Resolution and Intel® 11th Gen Core™ i5 CPU
Features
- Intel® 11th Gen Core™ i5 Processor
- Up to 64 GB RAM
- 1x CFast Card, 1x M.2 2280 NVMe
- 4x USB 3.2, 2x 2.5 GbE LAN, DisplayPort, HDMI
- 10.1" Capacitive TFT LCD Display
- Resolution of 1280 x 800p
- Wide Operating Temperature Range from -40°C to 70°C
- VESA Standard Mount
- IP65, FCC/CE Class A, and IEC-60068-2-1/2/14 Certification
The Panel PC LPC-P101WAG-3T7 from Elgens is a high-performance solution for demanding industrial applications that rely on robust performance and reliability. Equipped with an Intel® Tigerlake-U Core™ i7 processor, this Panel PC delivers impressive computing power for a wide range of applications.
The core feature of the LPC-P101WAG-3T7 is its 10.1-inch P-Cap touchscreen with an impressive resolution of 1280 x 800 pixels, ensuring a clear and razor-sharp display. The frameless design provides a seamless appearance while also allowing for easy cleaning and maintenance.
The Panel PC features a fanless design, which not only minimizes noise but also reduces maintenance requirements and extends the system's lifespan. Thanks to its wide input voltage range of 12 to 24 volts, the LPC-P101WAG-3T7 is highly flexible and can be used in various environments.
With its IP65-certified front panel, the LPC-P101WAG-3T7 is protected against dust and water, making it ideal for use in demanding industrial environments. Additionally, the 3-pin power terminal block ensures a reliable power supply.
Optionally, the Panel PC is available with a powerful 1000-nits LED backlight, enhancing readability even under direct sunlight.
Overall, the Elgens LPC-P101WAG-3T7 Panel PC is a top-tier choice for industrial applications that require high computing performance, a rugged design, and reliable operation.
Technical details
| Add-ons: | M.2 2230 E key, M.2 2242 B key, M.2 2280 M key |
|---|---|
| Audio: | Speaker out |
| CPU: | Intel® Core™ i5-1145G7E |
| CPU Generation: | 11th generation |
| Certificates: | CE Class B Compliant, FCC / CE Class A Certification |
| DC Input: | 3-pin pluggable terminal block |
| Display size: | 10,1" |
| Ethernet: | 2.5G |
| Ethernet Ports: | 1x, 2x |
| Humidity: | 10% ~ 90% (non-condensing) |
| IP protection class: | IP65 |
| Memory: | 1x DDR4 Slot, 2x DDR4 Slots |
| Memory capacity: | 2 GB, 4 GB, 8 GB, 16 GB, 32 GB, 64 GB |
| Mounting: | VESA |
| Operating Temperature: | -40°C ~ 70°C |
| Operating system: | Linux, Windows 10 IoT, Windows 11 |
| Power supply: | 12 ~ 24V DC |
| Screen resolution: | 1280 x 800 |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | CFast Card, M.2 2280 NVME |
| Touch: | Projected Capacitive Touch |
| USB: | USB 3.2 Gen 2 |
| USB Ports: | 1x, 2x, 3x, 4x |
| Video: | DisplayPort, HDMI |
