Nuvo-5006LP-PoE – Compact Industrial PC with PoE+

Reliable edge computing platform with integrated PoE+ functionality for industrial applications

Special price: €300 net (Barebone) directly from stock!

Product Overview

The Nuvo-5006LP-PoE is a compact, rugged industrial PC for versatile automation and monitoring tasks. Developed for industrial image processing, smart city applications, video surveillance and edge computing, the system combines high reliability with integrated PoE+ power supply for cameras and IP devices. Multiple PoE+ ports enable direct power supply to IP cameras or other network devices – without additional switches or injectors.

Price applies to the barebone system without CPU, RAM, or mass storage.

Nuvo-5006LP-PoE

Intel® 6th Gen Core™ i3/i5/i7/Pentium/Celeron CPU
Up to 32GB DDR4-2133 SD-RAM (two SO-DIMM slots)
USB 3.0, VGA, DVI, and DisplayPort connections
2x 2.5" SSD (+RAID 0/1) and 1x full-size mSATA slot
6x / 2x (PoE+) Gigabit Ethernet Ports
Fanless operation with a wide temperature range of -25°C to 70°C

Details

Enquire now - we recommend the right system for you

Briefly describe the area of application, interfaces and power requirements. We will get back to you quickly with a recommendation or a quote.

Last name *

Company *

Email *

Phone number *

Features (Application, interfaces, power requirements, ...)

By clicking 'send' you confirm that you have read and accept our data protection information and general terms and conditions. *

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Technical Overview: Nuvo-5006E-PoE

CPU Options (LGA1150)

Processor	Cores / Threads	Application Area
Intel® Core™ i7-6700/T/TE	4 / 8	Ideal for parallel AI workloads & industrial image processing
Intel® Core™ i5-6500/T/TE	4 / 4	High single-core performance for edge applications
Intel® Core™ i3-6100/T/TE	2 / 4	Stable industrial performance with optimized power consumption

Memory & Storage

Memory	Storage
2× DDR4 DIMM Slots Up to 64 GB RAM	2× 2.5" SATA SSD/HDD 1× 2.5" SATA SSD Hot-Swap 1× full-size mSATA Optional RAID 0/1

Interfaces & I/O

Category	Interfaces
Network	6× Gigabit LAN (Intel Controller)
USB	USB 3.1 Gen1, USB 2.0
Serial	RS-232/422/485 configurable COM ports
Display	VGA / DisplayPort
Hot-Swap	1× Hot-Swap for 2.5" SATA SSD
Power Supply	8–35 V DC wide range input with ignition control
Temperature Range	-25 °C to +60 °C
