POC-551VTC
Ultra compact In-vehicle controller with AMD Ryzen™ V1605B CPU, 4x PoE+, DIO and isolated CAN-Bus
Features
- AMD Ryzen™ Embedded V1605B quad-core CPU (15 W)
- Up to 16GB DDR4-2400 SDRAM
- 4x USB 3.0, VGA, DisplayPort, 2 serial ports
- 4x Gigabit PoE+ ports
- 1x CAN 2.0 port, 1x DIO
- M.2 2280 NVME, 3x miniPCIe, 1x mSATA
- Robust, fanless operation at -40°C ~ 70°C
- Wall or DIN rail mounting possible
Product information "POC-551VTC"
The POC-551VTC is a next-generation ultra-compact, fanless vehicle controller that offers unprecedented performance in this form factor. With its outstanding performance and reliability, the POC-551VTC sets new standards for vehicle applications—all at an attractive price.
Main Features of the DIN-Rail Vehicle PC POC-551VTC
- Powerful AMD Ryzen™ Processor: Equipped with the AMD Ryzen™ Embedded V1000 processor (V1605B) featuring 4 cores and 8 threads, the POC-551VTC delivers up to three times the CPU performance compared to previous POC models.
- Advanced PoE+ Connectivity: With four 802.3at PoE+ ports, the POC-551VTC powers devices such as IP cameras with up to 25 W while ensuring efficient data transmission.
- Wireless Communication: The POC-551VTC features one M.2 and three Mini-PCIe sockets, supporting various wireless modules such as 4G, 5G, and Wi-Fi, making it ideal for modern vehicle applications.
- Seamless Vehicle Integration: With CAN-bus integration, the POC-551VTC enables reliable onboard communication, while the isolated DIO facilitates the control of sensors and actuators.
- Reliable Power Supply: Thanks to its ignition control and wide DC input range, the POC-551VTC is compatible with a variety of vehicle types, offering maximum flexibility.
Why the POC-551VTC is the Ideal DIN-Rail Vehicle PC
The POC-551VTC offers a unique combination of compact design, exceptional computing power, and comprehensive connectivity. Its versatile features make it the ideal choice for demanding vehicle PC applications, from monitoring and data communication to control systems.
Choose the DIN-Rail Vehicle PC POC-551VTC to optimize your vehicle applications and benefit from a robust, high-performance, and future-proof solution.
Technical details
| Add-ons: | Full-size Mini PCIe, Full-size mSATA port, M.2 2242 B key, M.2 2280 M key, SIM Socket |
|---|---|
| Audio: | 1x 3,5mm jack mic in & speaker out |
| CPU: | AMD Ryzen™ V1605 |
| Certificates: | CE/ FCC Class A, according to EN 55032 & EN 55024, E-Mark, EN 45545, EN50155, IEC61373:2010, Category 1, Class B |
| DC Input: | 3-pin pluggable terminal block |
| DIO: | 4-CH isolated DI und 4-CH isolated DO |
| Ethernet: | Gigabit |
| Ethernet Ports: | 1x, 2x, 3x, 4x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Ignition control: | Yes |
| Internal Graphics: | Vega GPU with 6 compute units |
| Memory: | 1x DDR4 Slot |
| Memory capacity: | 2 GB, 4 GB, 8 GB, 16 GB |
| Mounting: | DIN-rail mount (optional), Wall-mount |
| Operating Temperature: | -40°C ~ 70°C |
| Operating system: | Linux, Windows 10, Windows 10 IoT, Windows 11 |
| PoE: | Yes |
| PoE+ Ports: | 4x RJ45 PoE+ |
| PoE-Standard: | IEEE 802.3at (PoE+) |
| Power supply: | 8 ~ 35V DC |
| Remote: | 3-pin pluggable terminal block for remote control, PWR LED Output |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | M.2 2280 NVME |
| TPM: | TPM 2.0 |
| USB: | USB 3.0 |
| USB Ports: | 1x, 2x, 3x, 4x |
| Video: | DisplayPort, VGA |
