Nuvo-10108GC-10G
Robust edge AI platform with 10G Ethernet port and support for one 350W NVIDIA® RTX™ GPU
Features
- Supports one RTX 350W graphics card
- Intel® 13th/12th Gen Core™ i3/i5/i7/i9 CPU
- Up to 128GB DDR5-4800 SDRAM
- 1x 2.5" SSD and 1x M.2 2280 NVME
- 6x USB 3.2, 2x serial interfaces, VGA and Displayport
- 2x 2.5G, 1x 1G, 1x 10G Ethernet ports
- 3 additional PCIe x8 slots for expansion cards
- Operating temperature -25 °C to 60 °C
Product information "Nuvo-10108GC-10G"
The Neousys Nuvo-10108GC-10G redefines embedded industrial PCs and is specifically designed for demanding applications in industrial automation, surveillance, and AI-based systems. Setting new standards in connectivity and performance, this system features an additional 10G interface for enhanced networking capabilities.
- NVIDIA® GPU Support: Equipped with advanced NVIDIA® GPU technology, the Nuvo-10108GC-10G provides impressive graphics and computing power for demanding applications in image processing, machine learning, and more.
- Expandability through PCIe Slots: With multiple PCIe slots, the device allows flexible expansion with additional cards to meet individual requirements, from interfaces to specialized accelerators and high-speed networking.
- Rugged Design for Industrial Applications: The Nuvo-10108GC-10G meets high standards for temperature, vibrations, and shock resistance. Its robust design ensures reliable performance even under extreme industrial conditions.
- High Memory Bandwidth: With support for powerful DDR5 memory, the system provides impressive memory bandwidth for computationally intensive applications.
- Operating System Independence: Compatible with various operating systems, the Nuvo-10108GC-10G allows easy integration into existing systems, providing maximum flexibility.
With the Neousys Nuvo-10108GC-10G, you get a reliable and powerful solution for your industrial applications with the added benefit of a 10G interface, enhancing your networking capabilities. Invest in the future of industrial automation with this innovative embedded system.
Technical details
| Add-ons: | 2x PCIe x8 Gen3 Slot, 3x PCIe x8 Gen3 Slot, Full-size Mini PCIe, M.2 2242 B key, M.2 2280 M key, M.2 3052 B key, PCIe x8 Gen3 Slot, PCIe x16 Gen4 Slot |
|---|---|
| Audio: | 1x 3,5mm jack mic in & speaker out |
| CPU: | Intel® Core™ i9, Intel® Core™ i7, Intel® Core™ i5, Intel® Core™ i3, Intel® Celeron®, Intel® Pentium® |
| CPU Generation: | 12th generation, 13th generation |
| CPU Socket: | LGA1700 |
| Certificates: | CE/FCC Class A, according to EN 55032 & EN 55035, MIL-STD-810H, Method 514.8, Category 4, MIL-STD-810H, Method 516.8, Procedure I |
| Chipset: | Intel® R680E |
| DC Input: | 3-pin + 4-pin pluggable terminal block |
| Ethernet: | 2.5G, 10G, Gigabit |
| Ethernet Ports: | 1x, 2x, 3x, 4x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Ignition control: | Yes |
| Intel AMT: | AMT 16.0 |
| Internal Graphics: | Intel® UHD Graphics 770 |
| Memory: | 1x DDR5 Slot, 2x DDR5 Slots |
| Memory capacity: | 4 GB, 8 GB, 16 GB, 32 GB, 64 GB, 128 GB |
| Mounting: | Damping brackets, Wall-mount |
| Operating Temperature: | -25°C ~ 60°C |
| Operating system: | Linux, Windows 10, Windows 10 IoT, Windows 11 |
| Power supply: | 8 ~ 48V DC |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | 1x M.2 2280 NVME & 2.5" SATA SSD, 2,5" SSD |
| TPM: | dTPM 2.0 |
| USB: | USB 2.0, USB 3.2 Gen 2 |
| USB Ports: | 1x, 2x, 3x, 4x, 5x, 6x, 7x |
| Video: | DisplayPort, VGA |
