Nuvo-11501
Compact and affordable fanless computer with Intel® Core™ Ultra 200S CPU
Features
- Intel® Core™ Ultra 200S 35W / 65W LGA1851 CPU
- Up to 64GB DDR5-6400 RAM
- 1x M.2 2280 Gen4x4 NVMe, 1x 2.5‘ / 3.5’ SATA HDD/SSD
- 2x 2.5 GbE, 4x USB 3.2
- 1x DisplayPort, 1x HDMI
- Fanless operation at -10 ~ 60 °C
- 8 - 48V wide range input
- Compact dimensions of 212 x 165 x 80 mm
- CE/FCC Class A and MIL-STD-810H certifications
The Neousys Nuvo-11501 is a cost-effective, compact, fanless embedded AI computer powered by an Intel® Core™ Ultra 200S series processor. It is an ideal solution for machine vision or factory automation applications that demand cutting-edge CPU performance, cost efficiency, minimal I/O, and flexible storage options.
Powered by the latest Core™ Ultra 200S processors, the Nuvo-11501 delivers nearly 120% of the performance while consuming only 80% of the power compared to the previous generation, thanks to TSMC's advanced 3nm process technology. In addition to its superior CPU performance, the Core™ Ultra 200S series also features an integrated Neural Processing Unit (NPU), providing enhanced AI inference capabilities alongside rule-based algorithms to meet the demands of modern machine vision applications.
The Nuvo-11501 offers essential I/O functions for industrial application needs, including dual 2.5GbE ports, dual display ports, and four USB 3.2 ports. Additionally, it features a Gen4 x4 M.2 NVMe slot for high-speed OS read/write operations, along with an internal 2.5"/3.5" SSD/HDD bay for high-capacity storage—ideal for data logging or video recording. For internal expansion, it provides two mPCIe slots and one M.2 E-Key slot for adding COM ports, Wi-Fi, or 5G/ 4G LTE connectivity.
Combining a proven thermal design with essential I/O functionality, the Nuvo-11501 delivers a rugged, compact, and budget-friendly computing solution tailored for a wide range of industrial applications.
Technical details
| Add-ons: | Full-size Mini PCIe, M.2 2230 E key, M.2 2280 M key, MezIO® Port |
|---|---|
| CPU: | Intel® Core™ Ultra 9 285/285T, Intel® Core™ Ultra 7 265/265T, Intel® Core™ Ultra 5 245/245T/225/225T |
| CPU Generation: | Intel® Core™ Ultra 200 |
| CPU Socket: | LGA 1851 |
| Certificates: | CE, CE/FCC Class A, according to EN 55032 & EN 55035, FCC Class A, MIL-STD-810H, Method 514.8, Category 4, MIL-STD-810H, Method 516.8, Procedure I |
| Chipset: | Intel® H810 |
| DC Input: | 3-Pin Pluggable Terminal Block |
| Ethernet: | 2.5G |
| Ethernet Ports: | 1x, 2x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Ignition control: | Yes |
| Internal Graphics: | Integrated Intel Xe Graphics |
| Memory: | 1x DDR5 Slot |
| Memory capacity: | 8 GB, 16 GB, 32 GB, 64 GB |
| Mounting: | DIN-rail mount (optional), Wall-mount (optional) |
| Operating Temperature: | -10°C ~ 60°C |
| Operating system: | Linux, Windows 10, Windows 10 IoT, Windows 11, Windows 11 IoT |
| PoE: | No |
| Power supply: | 8 ~ 48V DC |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | 2,5" SSD, M.2 2280 NVME |
| TPM: | fTPM 2.0 |
| USB: | USB 2.0, USB 3.2 Gen 1 |
| USB Ports: | 1x, 2x, 3x, 4x, 5x, 6x |
| Video: | DisplayPort, HDMI |
