NISE-51
Fanless compact IoT Gateway with Intel N3350 Dual Core CPU
Features
- Intel N3350 Dual Core CPU
- Up to 8GB DDR3 RAM
- 16GB - 32GB Onboard EMMC + optional M.2 2242 module
- mPCIe Slots for optional addon cards
- USB 2.0 / 3.0, 3x COM, 1x DisplayPort
- 12V / 24V DC input
- CE/FCC certified
Powered by the latest generation of Intel® Celeron® processor N3350 (formerly codenamed "Apollo Lake"), NISE 51 series positions at the intelligent IoT gateway for factory automation and for smart city applications. DDR3L SODIMM memory socket, the NISE 51 series support operating temperature from -10°C to 60°C with 12V/24V DC input with +/-10% range. The NISE 51 series have strong connectivity - Ethernet-based LAN port and traditional RS485, mainly for Modbus TCP or Modbus RTU communication. For wireless connectivity, there are 1 x mini-PCIe sockets and 2 x M.2 slots which can support optional wireless modules for IoT applications, for example, Wi-Fi, Bluetooth, 3.5G and 4G LTE module as well as storage module. NISE 51 is definitely the best choice for M2M intelligent system as an intelligent IoT gateway.
Technical details
| Add-ons: | Full-size Mini PCIe, M.2 2242 B key, SIM Socket |
|---|---|
| Audio: | Speaker out |
| CPU: | Intel N3350 |
| Certificates: | CE, FCC Class A |
| DC Input: | 3-pin pluggable terminal block |
| Ethernet: | Gigabit |
| Ethernet Ports: | 1x, 2x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Memory: | 1x DDR3 Slot |
| Memory capacity: | 2 GB, 4 GB, 8 GB |
| Mounting: | Wall-mount |
| Operating Temperature: | -10°C ~ 55°C |
| Operating system: | Linux, Windows 10 IoT |
| Power supply: | 12V DC, 24V DC |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | M.2 2242 NVMe, On-board EMMC |
| USB: | USB 2.0, USB 3.0 |
| USB Ports: | 1x, 2x, 3x, 4x |
| Video: | DisplayPort |
